High Speed Ethernet Patch Cord , UTP Cat5e Patch Cable IEEE 802.3

Quick Detail:

1. 4 pairs 24awg Cat5e UTP Patch Cable /Patch Cord, unshielded

2. Conductor: 7/0.2mm Bare copper , soft annealed bare copper.

3.Insulation: America Dow's HDPE

4.Contact: FU/1U/3U/6U/15U/30U/50U gold plated

5.Outer jacket: PVC or FRPVC

6.Any color and any length is optional .

7. Test :Pass fluke test and with 25 years quality warranty.

Application

*10 Base-T (IEEE 802.3)

*Fast Ethernet (IEEE 802.3u)

*100vg-AnyLan(IEEE 802-12)

*Token Ring(IEEE 802.5)

*TP-PMD(ANSI X 3T9.5)

*ATM 155

*Gigabit 1000Mbps(802.3z)

Industry Standard

*UL ETL Verified

*TIA/EIA 568B.2

*ISO/IEC 11801

Specifications

Fire resistant :CM ,LSZH ,CMR

Description

Cable

*Conductor: 7 copper wires Ø0.20 mm (0.008"), 24 AWG

*Insulation: High Density Polyethylene (HDPE)

*Diameter of insulated conductor: 0.98 ± 0.05 mm (0.039" ± 0.002")

*Number of pairs: 4

*Color of twisted pairs: blue-white/blue, orange-white/orange, green-white/green, brown-white/brown

*Drain wire: 7 wires Ø0.20 mm (0.008")

*Jacket: PVC Ø5.5 ± 0.2 mm (0.22" ± 0.008")

Plugs

*2 pieces RJ-45 8P8C

*Contact: FU/1U/3U/6U/15U/30U/50U gold plated

*Latch guard Material: PVC or FR-PVC
